Blog # 7 8/1/2010

NOAA Teacher at Sea: Story Miller

Launching the XBT

NOAA Ship: Oscar Dyson

Mission: Summer Pollock III

Geographical Area: Bering Sea

Date: August 1, 2010

Time: 1233 ADT

Latitude: 60°51N

Longitude:179°11W

Wind: 17 knots (approx. 19.6 mph or 31.5 km/h)

Direction: 171° (S)

Sea Temperature: 9.9°C (approx. 49.8°F)

Air Temperature: 12.8°C (approx. 55.0°F)

Barometric Pressure (mb): 1009

Wave Height 2-3 feet

Swell Height 4-6 feet

Scientific Log:
Think about your morning routine from the moment you wake up to just after eating breakfast. Now imagine spending that morning on a boat in the middle of the Bering Sea. Perhaps you take a shower or wash your face and hopefully brush your teeth. Where does the water come from? Where does the waste water go? I bet at some point you will use the bathroom (Hey, it’s a fact of life and everybody does it!). Where does that waste go? How is it processed? I also bet that at some point you turned on the light. How does a boat get its electricity?

The Oscar Dyson has a truly remarkable system that allows a crew of up to 39 live on the ship for as long as we have food and fuel! The fuel used is diesel and the diesel is converted into electricity through the engine, which turns the generator and the generator makes AC power. A rectifier ridge turns the AC power into DC power and the DC power runs to the shaft which is able to turn the propeller. However not all the power goes to DC power. The rest is turned into AC power so that we can use lights, heaters, fans, and the ovens in the galley.

Below the deck of the ship is where the engineers maintain all the components that make the ship function.

The Machines:

The main shaft (what turns the propeller on the ship)

Because we would not be able to go anywhere without fuel, let’s start with it. The fuel goes from the fuel tank to a primary filter and then through a secondary filter to clean the fuel. The fuel then travels to the fuel pump which transfers it to the injector and the injector sends it to the engine.

The centrifuges that clean the fuel.

Whatever fuel is not used is returned to a storage tank where it will wait until we need it again. Because fuel can become dirty when it sits, and dirty fuel is not good for engines,  the old fuel is run through a centrifuge (a device that spins and uses centrifugal force to separate mixtures) to become purified. As you can see in the picture, there are two centrifuges because it is important to have a backup in case of a breakdown. One is currently running for the month of July and the other will run for the month of August. We have this alternating pattern because we want to make sure there is even wear on each.

Access hatch to the waste oil storage.

Entering confined spaces are dangerous

as noted by the bolted entry. Special

protective materials, a work plan, and

an initial safety test must be in place prior to entry!

Periodically, the ship requires an oil change and the waste oil from machines such as the crank case, winches, and hydraulics are placed in a storage tank. Because it costs a considerable amount of money to haul waste fuel, the ship has a method for disposing it. From this waste oil storage tank, it is pumped up to the incinerator where it is burned.
The ship will also obtain oily water from locations such as the bilges and that water is recycled by going through the Oily Water System (OWS) and currently it is able to clean the water to 15ppm (parts per million) of oil to water. After the purification it is released into the ocean. We are currently in the process of installing another filtration system that will run the 15ppm concentration and reduce the contaminants to 5ppm and possibly even 3ppm. The oil that is extracted from the water is put into the waste oil storage tank for future incineration.

Engineering Control Room

As stated earlier, all the machinery, including the coffee maker, is maintained by the engineers. In the control room the engineers are able to monitor all functions of the ship. If needed, they could even take away the power from the bridge (where the NOAA Corps officers control the ship) and drive the ship from underneath! So, if you really want to be in control...

Sanitation:
Some may wonder what we do with all of the garbage we collect on the ship. For example, where does all the uneaten food go? What about all the paper waste from used cups, napkins, and wrappers? In the mess hall, there are two garbage bins, one to scrape uneaten food and the other for paper. Because food is biodegradable, that bin is tossed overboard. The paper waste is sent to the incinerator to be burned. I am told that the incinerator gets hot enough that if a soup can was placed inside and incinerated, it would appear to look normal after the incineration, except once you touch it, it crumbles into dust!

To get clean drinking water, we pump the salt water from the ocean into a desalination unit (a distiller). The distilled water is then sent to a 10,000 gallon holding tank. When water is needed, it is pressurized which, like in your house, sends it to the faucets, drinking fountains, and shower. Perhaps you have heard of the pens using UV light to purify water when you are camping. Well, right after the water is pressurized the boat has a large UV Pen to kill any additional microbes that might be inhabiting the water.

Marine Sanitation Device

From the toilet, the waste material is pulled down by a vacuum and travels through a pipe to the Marine Sanitation Device (MSD) tank. All the waste, including what we call “gray water” which basically is waste water from the shower and the sink, is agitated with an aroator. Solid waste will sink to the bottom of the tank where it is ground to fine particles. Oddly enough the grinder is also responsible for the vacuum in the sewage line via the eductor. The dirty water mixture is then sent through the chlorinator and is stored in the chlorination tank. When the water rises to a certain point, a sensor signals the pump to send the chlorinated water over the side of the boat.

Cool fact! On other ships in the past, the catch water in the toilets was salt water (the Oscar Dyson uses fresh water). Because the water in the toilets did not need to be distilled, little bioluminescent organisms would sit inside. The thrilling activity is that when a person would flush the toilet in the dark, the organisms would become agitated and glow. Therefore, in your toilet, you could have your own light show with each flush!

Personal Log:

Squid

Today we processed one batch of fish. The odd part to this scenario was that we caught a group of Pacific Herring. We measured, weighed, and extracted stomach samples as it is equally important to gather data about other fish we catch. The internal body structure of a Pacific Herring is very different from that of a Walleye Pollock and so I had the opportunity to dissect and study a different kind of fish. Leftover critters from the trawl that occurred last night while I was sleeping also appeared in the catch - tiny jellyfish, squid, and shrimp - and I spent some time sorting them out. Tonight, our chef is cooking up a few of the herring so we can see what they taste like. Another highlight to working with the herring is that I was challenged to locate and extract the otoliths. The otoliths of Pacific Herring are much smaller than those of the Walleye Pollock. To provide an idea, imagine clipping your pinky toenail. The clipping would be just a little larger than the otolith! Otoliths of pollock are a little less than one centimeter long and 1/2 of one centimeter wide.

Jellyfish

Today we crossed the 180° line of Longitude and entered the future, putting me a day ahead of the United States. Currently our transect has placed us near Cape Nevarin, Russia and unfortunately it is too foggy outside to see land. Because I have crossed the  dateline, I will receive the Order of the Golden Dragon, a certificate proving my adventure across the line!

I am exceptionally excited for dinner tonight as we are having King Crab legs, prime rib, mashed potatoes and gravy, and of course, some herring! With Ray as our chef, it is evident that nobody goes hungry! Today he constructed a shortcake in the shape of the Oscar Dyson, decorated it, and set aside a bowl of strawberry sauce. I would have taken a picture but by the time I finished processing the herring, the cake ships were in fatal condition for sailing but I feel the crew are quite satisfied!

Animals Spotted Today:

Immature Gull

Humpback whales
Walleye Pollock
Pacific Herring
Shrimp
Squid
Jellyfish
Northern Fulmars
Black-legged Kittiwakes
Slaty-backed Gulls

Something to Ponder:
I decided that it was important to inquire what it took to be an engineer on the boat. After talking with a few members of the crew who had been doing this line of work for a long time, I was loaded with valuable insight to pass along to my readers.
According to the engineers, the best way to guarantee a well-paying job on a boat and allow one to have more options available would be to attend a maritime school because graduates will walk onboard with an officers ticket. While college is expensive, consider this: If you attend the US Merchant Marine Academy (USMMA), your college is paid for as it is one of the five US service academies. www.usmma.edu

However, because admission is difficult, if you were to attend a maritime academy, you could potentially have a situation similar to one of our engineers on board. He attended Maine Maritime Academy for four years and earned a Bachelors of Science in Engineering. Additionally, within six months of working onboard a ship with his credentials, he had ALL of his student loans paid for! Most college students in the US spend approximately five years paying off their student loans!

While a maritime academy would be ideal, I asked the engineers of other ways one could obtain an engineering/mechanic job on a ship. They shared that there were 2-year schools available but the largest drawback to that path is that upon graduation, you would have some skills but would not be fully licensed. One rule of thumb that I have learned over the years, and the engineers echoed this, is the key to having choices in your job is to become as versatile as possible.
I then asked the engineers if there were any other ways to get a job on a boat and they mentioned that one could attend a union school and learn a trade such as in refrigeration or mechanics. Keep in mind though, that person would be unlicensed and not have as many choices available to them.

I also asked the engineers what subjects in school they thought were the most important to learn. The first subject mentioned was mathematics but they brought up a very important concept: “It’s not necessarily how much math you take, but how well you understand the math.” Think of a student who aces the test and then forgets everything afterward. In other words, it would be great if a student made it to Calculus in high school but if he or she doesn’t fully understand the processes behind the algebra, that student will have difficulty in his or her engineering occupation. The engineers also shared that trigonometry was essential.
Regarding the sciences, for engineering, it was highly recommended that students wanting to get off on the right foot should take chemistry, physics, and biology.

However, one of the most important subjects they mentioned that may surprise some readers is English Composition because “You must have the ability to express yourself effectively and communicate with the people you work with everyday.” The engineers shared that, for example, they often would have to write reports and if they needed a part, the engineers would need to write to a supervisor and provide reasons to prove why they would need a part. “The better you are at communicating, the farther you will be able to go with your job and get what you want.”

So, in closing, the next time you think, “Geeze, why do I need to learn this equation and how to use it in this silly word problem?” or, “Why do I need to write this paper about persuading my English teacher that peanut butter and jelly sandwiches are the best?” remember this: Your teachers really are not torturing you and really, are simply training you to develop the skills you will need to utilize in your job and in adulthood. The more advantage you take of this training, the more versatile and successful you will become. Ultimately though, it’s up to you to make that move!

For more information a valuable website is: http://www.omao.noaa.gov/about.html

Blog #6 7/29/10

NOAA Teacher at Sea: Story Miller

NOAA Ship: Oscar Dyson

Mission: Summer Pollock III

Geographical Area: Bering Sea

Date: July 29, 2010

Time: 1922 ADT

Latitude: 59°47N

Longitude:178°14W

Wind: 5 knots (approx. 5.8 mph or 9.3 km/h)

Direction: 9.8° (N)

Sea Temperature: 10.1°C (approx. 50.2°F)

Air Temperature: 8.7°C (approx. 47.7°F)

Barometric Pressure (mb): 1015

Wave Height: 0 - 1 feet

Swell Height: 1 - 2 feet

Scientific Log:

I decided that it would be beneficial to provide some information regarding some of the animals I have seen over the past week.

Short-tailed Albatross (Phoebastria albatrus)

Yesterday morning during breakfast, one of the NOAA Corps Ensigns came down to tell me that there was a Short-tailed Albatross off the port side (left side) of the boat. This was a very special event, especially if you are an avid birder because currently there are about 2000-2500 in the world. The short-tailed albatross is one of three species of albatross living in the North Pacific Ocean and is the largest of all seabirds in this location. This bird has a wingspan of approximately two meters. One could conclude that the bird I saw was younger because young short-tailed albatross have “chocolate brown” feathers when young and as they grow larger they turn white. This bird likes to eat squid, small fishes like pollock, and zooplankton. The albatross population dwindled because the birds were very easy to access due to them only nesting on a couple islands in Japan and they were not afraid of humans. As a result they were really easy to kill and because there was a high market value for their feathers, hunters pursued them to near extinction. In fact it is said that in 1953 there were only about 10 pairs left in the world.

Northern Fulmar (Fulmarus glacialis)

Northern Fulmar

This species of bird has been consistently following our ship since we left Dutch Harbor. They are primarily a pelagic bird which means that unless they are breeding, they are living out at sea throughout the year. The Northern Fulmar can be found in a range of different colors depending on where they were born. Generally, the darker birds are found in the southern parts of Alaska and the white are found farther north. However, if you are on the Atlantic side of the US the pattern is just the opposite with the darker birds originating in the high Arctic and the light are found farther south! These birds typically feed on squid and small fish.  One fact that I find fascinating about the Northern Fulmars is that they have the ability to launch their puke up to 6 feet as a defense mechanism! I shall now remember it as the projectile vomiting bird!

Black-legged Kittiwake (Rissa tridactyla)

One interesting fact about this bird is that it has only three functional toes, hence the tri prefix in its scientific name. These birds are white and their wings are gray. Because I grew up in the desert, my untrained eye mistakenly identified them as a seagull but thanks to USFWS scientists Marty Reedy and Liz Labunski, I am now informed of the differences! This bird is also pelagic and their breeding season is during this time. These birds feed on small fish and they are found around the coasts of Alaska, the Bering Sea, and in the northern Canadian Atlantic Coast. When the black-legged Kittiwake feeds, it usually catches its prey on the surface of the ocean but it has been known to plunge underwater. Typically they feed on zoopankton.

Red-legged Kittiwake (Rissa brevirostris)

As stated in its name this bird has bright coral red legs and is typically shorter than the Black-legged Kittiwake. These birds are most commonly found mostly in the Pribilof Islands and there are only about five or six places in the world where they breed, all of which are in the Bering Sea.

Short-tailed Shearwater (Puffinus tenuirostris)

These birds are known to breed off Australia. In the summer they migrate to Alaska, a trip of about 9000, and have been known to take as little as six weeks! In Australia they are important in the Aboriginal culture in Tasmania and are commercially harvested for food, feathers, and oil. These birds usually eat crustaceans but are also known to eat fish and squid. To catch their prey, they will plunge or dive into the water. One interesting adaptation is that they are able to convert their food to oil and the benefit is that oil does not have as much weight as an ingested animal which allows the birds to travel long distances.

Fork-tailed Storm-Petrel (Oceanodroma furcata)

When I first saw these birds I thought a bat was flying over the water due to a slightly more erratic flight pattern than the smooth flights of the other birds I have observed. These birds typically feed at the surface of the water. Fork-tailed Storm-Petrels are also pelagic, living approximately 8 months at sea and when they do return to their breeding grounds in late-spring, they will dig burrows in the soil or find ideal nest locations in rock crevices. The baby chicks are thought to have a unique adaptation for survival. Sometimes the parents leave the baby alone for many days to look for food. During this time the baby’s body head drops into a state of torpor until the parents return and raises its body temperature.

Pomarine Jaeger (Stercorarius pomarinus)

These birds are capable of backward somersaults in the air and take part in acts of piracy as they have been known to harass other birds until the lesser bird gives up its food. The Pomarin Jaegers primarily feed on lemmings and even have a reproductive period that is dependent on the brown lemming! According to the USFWS they are “the only avian predator that digs for lemmings.”

Smooth Lumpsucker (Aptocyclus ventricosus)

Smooth Lumpsucker

Lumpsuckers live in cold waters in the Northern Hemisphere. They have a disk underneath their body that allows them to cling to rocks. “All but a few lumpsuckers have spiny tubercles on the head and body” (2002).  There are 27 species of lumpsuckers and 10 are confirmed to occur in Alaska with 3 more species are known to be near Alaska. These fish can be found on the bottom of the sea, usually on the continental shelf.

Personal Log:

The suction disk of the Smooth Lumpsucker

After my shift ended yesterday, I hung out on the bridge and looked at seabirds and tried to find evidence of land (Russia) since we are so close. The day was clear and sure enough, right after supper, Russia was spotted! While I have not been out to sea that long, the idea of land coming into view was an exciting feeling. Perhaps the feeling was because the land belonged to Russia and I had never been there before or that the sighting of land broke up the monotony of the never-ending stretch of moving water. I feel that the feeling was derived from a little bit of both. While I was searching for Russia, I had the opportunity to observe a Fin Whale about one mile (~1.5km) ahead of the boat. A few times, it came out of the water enough so that you could see its total back and dorsal fin! For me, Fin Whales have been the most commonly spotted.

This morning, after repeatedly launching the experimental Cam-Trawl with no results, we finally snagged a picture of a fish early this morning! The picture was very dark and the fish, mostly a blur but it was obvious that the image was a fish! This is yet another example of how a scientist must be patient as it is common in real-life experiments, as opposed to structured labs in the classroom, to have tests fail multiple times before useful results occur!

The first fish photographed by
the Cam-Trawl!

In the evening, I decided to spend time on the bridge again and watch for whales. I was in luck yet again as I was able to see two Humpback whales! They were swimming very close to the ship, but not close enough for the zoom on my camera! I was able to watch them for a good twenty minutes before they “fluked” (showed their tail) and dove deep underwater!

Overall it was a very interesting couple of days!

Citations:

Denlinger, L.M. 2006. Alaska Seabird Information Series. Unpubl. Rept., U.S. Fish and  Wildl. Serv., Migr. Bird Manage., Nongame Program, Anchorage, AK

Mecklenburg, C.W., Mecklenburg, T.A., & Thorsteinson, L.K. (2002). Fishes of alaska. Bethesda, MD: American Fisheries Society.

USFWS scientists Liz Labunski and Marty Reedy

Animals Viewed:

Walleye Pollock

Pacific Herring

Smooth Lumpsucker

Shrimp (unidentified) but they looked like what I have for dinner!

Jellyfish

Fin Whale

Humpback Whale

Short-tailed Albatross

Northern Fulmar

Something to Consider:

Many people, including myself, enjoy watching animals but never learn what their common names are! We take for granted the wonders of Mother Nature that we see everyday and sometimes disregard them as being "normal." However, what you see may not be normal for other people, such as seeing high populations of bald eagles in Dutch Harbor and Unalaska! It is never too late to learn and if, for example, you move to a different location with different flora and fauna, you can share with your new friends the environment from which you came! I find when traveling to other countries or other locations in the "Lower 48" that they assume Alaska is always cold, snowy, and that penguins live there (which they don't)! When I take my pictures with me, it is exciting to see other people's reactions and the conversations afterward are always engaging!

Now would be a great time to photograph the animals and plants you see inhabiting the land surrounding your home. You never know when you may bump into an avid "birder" or other animal specialist that could tell you their names. Or, if you are feeling particularly enthusiastic on a foul weather day, there are many identification books available in your local library.

Blog #5 7/27/10

NOAA Teacher at Sea: Story Miller

NOAA Ship: Oscar Dyson
Mission: Summer Pollock III
Geographical Area: Bering Sea
Date: July 27, 2010
Time: 1940 ADT
Latitude: 60°28N
Longitude:177°51W
Wind: 8 knots (approx. 9.2 mph or 14.8 km/h)
Direction: 270° (W)
Sea Temperature: 9.2°C (approx. 48.6°F)
Air Temperature: 9.1°C (approx. 48.4°F)
Barometric Pressure (mb): 1007
Swell Height: 1 foot (about 30.5 cm)
Wave Height: 0-1 foot (about 30.5 cm)

Scientific Log:

There are many different groups of people working aboard the ship, Oscar Dyson - Scientists, NOAA Corps officers, Deck Hands, Engineers, Survey Technicians, and Cooks. Within the science department, there are 12 members aboard and two Teachers at Sea which totals to 14 souls. For this third leg of pollock surveys, the chief scientist is Taina Honkalehto. Her job aboard the ship is to plan the scientific activities and make the decisions on how best to carry out that plan. Of the scientist crew, there are two Russian scientists that are conducting their own research in collaboration with NOAA.
This pollock survey, which focuses on determining abundance and distribution, is an important component of the fishing industry in the United States. According to The Bering Sea Project, “The largest concentrations of pollock occur in the eastern Bering Sea,” and more specifically, “Walleye pollock support the largest single commercial fishery in the U.S., producing the largest catch of any one species inhabiting the 200-mile US Exclusive Economic Zone.” Additionally, the pollock industry is incredibly important to the people living in Dutch Harbor and Unalaska because pollock is one of the main fishes processed there and has helped classify Dutch Harbor as America’s #1 fishing port in the USA for fish landed (NOAA, 2009).

View of a spread out group of pollock as seen from

the computer screen. Notice in the far right corner a

red spot. That shows that at that location,

the fish are densely packed. The red, yellow,

and green-blue line represent the seafloor.

There are two summer surveys being conducted to estimate the Bering Sea pollock population: Acoustic-Trawl Survey and the Bottom-Trawl Survey. Currently on the Oscar Dyson we are conducting the Acoustic -Trawl Survey. After we catch the fish, we combine the acoustics, fish samples, and CTD deployment data, to draw conclusions that help us estimate population size and ecological factors of pollock. Remember, in order for pollock to live where they do, they need food and so when we extract stomach samples, we are looking for what pollock prey upon (mostly krill). Besides, food, other important aspects of their habitat must be in place for their survival. The CTD data -  water temperature, salinity, nutrients, oxygen, and chlorophyll - help us understand how the distribution of pollock has changed in past years and may also provide information about how it could change in the future.

However, not all of the scientists on board are collecting data related to pollock. Currently we have two other subgroups with one observing seabirds and the other observing marine mammals. The crew observing seabirds have a goal of observing species seen during the tour to determine seabird species distribution and abundance. The marine mammal observers are working to obtain current data on cetacean species distribution and abundance.

The Teachers At Sea (TAS), which currently include Obed Fulcar (New York, New York) and myself (Dutch Harbor, AK) have an important role of working under the scientists and other crew members to learn about the research being conducted in an attempt to bring real science into the classrooms.

A large group of fish scattered about
from the perspective of the transducer.

Because acoustics is a major tool used in pollock survey, I feel it would be beneficial to provide a few details on how it works. Remember, referring to Blog #2 “the ship has Transducers that send pings of sound energy down through the ocean and when they hit some object, such as the bottom of the ocean or a fish, in this case they are hitting the swim bladders of the fish, some of the energy in the sound ping is returned to the ship and received by our echo sounding system in the acoustics lab of the ship.” It is important to note that the acoustics under the water are different than in the air because the pressure in each location is different. Inside the acoustics lab there are many different screens that display the pings at different frequencies of sound waves. We know that jellyfish tend to show up the best from the low frequencies. Acoustics is a good tool to use to study pollock because pollock is the primary fish species inhabiting the middle-waters of the Bering Sea shelf. For example, bottom fish are difficult to see because the acoustic signals from the seafloor are too strong and tend to hide the bottom fish signals. Acoustic signals that we see on the computer screen rely on the actual physiological make-up of the fish. Also, the behavior of pollock plays a role in how we can see them acoustically. For example, salmon do not swim in large schools like pollock. When we see large schools of pollock on the acoustic screens, density determines the color - blue usually is reflecting a couple fish whereas red represents a high density of fish - and the shape of the schools tend to be typical of pollock. Through acoustics, we are able to survey pollock over a wide area and gain information regarding their distribution and population.

Prior to fishing, we consistently monitor the screens as the ship travels up and down the rectangular transects you can see when you view the ship’s path on ShipTracker. When we observe schools of fish, we need to decide whether they are large enough to sample the fish with the trawl. Because we also want to target certain ages of fish, it is important to be able to estimate their size.

We can estimate size through a method using additional measurements from the acoustic data. We draw a box around an area that is not densely packed with pollock so it is easier to distinguish an individual acoustic image of a fish. The software we have gives us the average intensity of the acoustic pixels. We call this intensity target strength which translates to the size of the echo. Because the size of the swim bladder is proportional to the size of the fish, we can use the intensity of the echo off the swim bladder to estimate the size of the pollock. In short, target strength depends on the size of the swim bladder and features of the swim bladder can be used to predict fish size.

Acoustic image from the bridge.

The bottom blue streak is a large

group of fish that ducked under the

net. The horseshoe shape is the net.

The blue inside the horseshoe are the fish.

We can use an equation for calculating decibels to help us estimate the size of the fish in the school we might target.  For my friends and students who are math gurus, the equation is TS = 20Log(length cm) + b20. The b20 variable is different for different fish species and so for Walleye Pollock in the Bering Sea, b20 is -66. Therefore, the equation for Walleye Pollock is TSpollock = 20Log(length cm) - 66.

To provide an example of how the equation works, lets say that the average length of a two year-old pollock is 25 cm and that is the size we want to target. We take that 25 centimeters and “plug it” into the section of the equation that stands for length in centimeters. Scientific calculators are wonderful devices for logarithms as they have the Log function already installed, and if you plug in 20Log(25) - 66 into the calculator, the answer -38.4 translates into the target strength that would show up on the screen. So if we find schools of pollock and see that the target strength is close to -38.4, then we know the echosounder is observing two-year old pollock.

Once acoustics have determined that we need to fish, they send the coordinates they want the Officer of the Deck (OOD, a.k.a. the NOAA Corps officer on watch on the bridge) to follow and the officers drive the ship to the location. On the bridge of the ship, the scientists are able to see the acoustic screens and are able to keep an eye on the location of the fish, relative to the transducer underneath. From there the Lead Fisherman or Chief Bosun operates the machinery required to put the trawls in the ocean. After the large mesh net is placed in the ocean, the crew put on a sensor that measures water depth and temperature. They also install a tool, called a headrope unit, that is similar to a mini transducer which makes an image of the mouth of the net and allows the scientists to watch fish entering the net from the bridge.

Senior Survey Technician, Kathy Hough,

and Ordinary Seaman, Frank Footman, installing

the head-rope unit.

Once the fish are caught, the deck crew will draw the nets back onto the boat using hydraulics. From the stern (back of the boat), the fish go into the fish lab on a conveyer belt where we sort, sex, measure, and extract stomachs and otoliths. Since being on the ship, during my shift we have been averaging two trawls per day.

How is the information we collect used?

On the ship, we are collecting raw data, entering into our computers, and analyzing what we see. From there, we can draw conclusions based on what we have observed from our samples. However, there are other scientists at work here. For example, perhaps you are interested in working with computers and want to be involved with wildlife. Some of the scientists help design the computer programs we use and maintain them. Perhaps boat life is not your "cup of tea." All the stomach and otolith samples we collect need to be sent into a lab to be analyzed by a stomach or otolith expert. The data they compile from the samples we collect get added into our publication at the end of the survey. There are also scientists that compile our conclusions about what we saw on the ocean and they create models to show population trends and predict future abundance. From that information, a council of scientists, industry representatives, and others of interest, get together and determine things such as fishing quotas. Also, don't forget that there are teachers, like me, aboard who take some of the scientific information or scientific processes and educate students about real science in the real world.

If you want to obtain a job working in the sciences department of NOAA, some courses of study that will increase your chances of becoming involved include but are not restricted to: Marine Biology, Chemistry, multiple levels of mathematics, Computer Science, Writing. Versatility is another key factor to consider for any job you may want to pursue as the more background information you have, the more information you can "bring to the table." For example, perhaps you love music. An understanding of decibels and how sound is carried at different frequencies is incredibly useful in acoustical sciences. Foreign Language is always beneficial as you will continually work with people from all over the world and remember, there are two scientists currently on the ship who are from Russia! Therefore, in my opinion, don't forget about your electives when choosing your courses because the more rounded you are, the greater your chances are for success!

Personal Log:

My morning started off fantastic as I was able to launch an XBT into the water again. By the time I was beginning to type this blog we passed over a school of pollock and decided that we needed to turn around and go fishing. Approximately two hours of sorting commenced before I was able to return. I learned that acoustics is a very difficult concept to explain as there are many factors in mathematics and physics that are complicated to translate into layman’s terms. I ended up spending a lot of time reading a textbook on the research the theories of using acoustics on wild fish. Please do not hesitate to ask in the comment box below this post if you have questions!!!
Overall, there was a good assortment of fish today and I stayed fairly busy in the fish lab collecting pollock sample data!

Me giving the fish a layer of water so that they slide down the

chute and onto the conveyor belt easier.

Animals Seen Today:
Walleye Pollock
Silver Salmon
Northern Fulmar
Parakeet Auklet
Short-tailed Shearwater
Least Auklets
Tufted Puffin
Thick-billed Murre
Northern Fur Seal

Something to Ponder:
Life at sea can be an amazing experience but there are many things people may take for granted when living on land. For example, consider the possibility of becoming hurt on the job, or developing a medical condition such as a rash or appendicitis. From the middle of the ocean, it is very difficult to reach a doctor to get a diagnosis. On board the ship, we have some medical supplies but typically there is not a licensed doctor on board the ship. Would you know how to respond to an emergency if it were to happen? If you have taken a First Aid or CPR class, do you remember what you need to do? How would you react? What would you do to reach help? Who could respond to your call?
For the Oscar Dyson we have the following protocols:
1. Contact the medical officer on board for an initial diagnosis.
2. If the condition requires advanced medical care, he or she will contact the medical officer on call at the NOAA Marine Operations Center.
3. In the case of an emergency and when the Marine Center cannot be contacted, he or she will contact the Maritime Medical Assistance (MMA).
4. If needed, we will arrange for a medevac (medical evacuation) which could involve the US Coast Guard and/or head back to port.

Blog #4 7/24/10

NOAA Teacher at Sea: Story Miller

NOAA Ship: Oscar Dyson
Mission: Summer Pollock III
Geographical Area: Bering Sea
Date: July, 24, 2010
Time: 1837 ADT
Latitude: 62°11N
Longitude:177°52W
Wind: 15.1 knots (approx. 17.4 mph)
Direction: 156° (SW)
Sea Temperature: 8.3°C (approx. 47°F)
Air Temperature: 7.4°C (approx. 45.3°F)
Barometric Pressure (mb): 1007
Wave Swells: 4 - 5 feet
Wave Height: 1 - 2 feet
Combined: 5 - 6 feet

Scientific Log:
Today started out with the launching of another CTD (Conductivity, Temperature, Depth) and XBT to measure the salinity and temperature of the ocean. On average we typically deploy a little more than one per day, depending on whether we are wanting to hit key locations. Today when we launched two and contrasted locations where there were pollock to locations where there weren’t so we could better analyze how sea temperature affects where the pollock prefer to hang out.

Survey Tech, Robert Spina, taking samples from the CTD

We attempted to launch the Cam-Trawl this morning but as is typical with new equipment, we encountered some problems once it was in the water. And as my students have learned, sometimes it’s necessary to make modifications and try the science experiment again! Even the pro’s must go through the Scientific Method multiple times before they can publish their findings!

Ovaries of a female Walleye Pollock

At approximately 1030 we deployed the AWT and went fishing for more pollock. This time we were able to gather a variety of different ages between the years 1-3. Once the fish are dumped from the codend, they are placed on a type of conveyor belt that allows us to do a preliminary sort through the fish. For example, jellyfish are commonly caught in the net and so we place them in a separate bucket to measure later. Sometimes we accidently catch other fish in the net, this is called bycatch, and they too need to be separated. At the end of the conveyor belt another person weighs baskets of fish and records the weights in the computer. Afterward, we take a random sample of about 400 fish and sex them. This sample is used to determine how many fish of each size are in the sample.  Unfortunately we do not have a way to identify the sex of the fish without having to cut into them to see. In addition to measuring, weighing, and sexing the fish, we again took samples of pollock stomachs and otoliths. We conducted two fish hauls during my shift and we will probably do two more tonight.

Testes of a male Walleye Pollock

When we finish collecting the data we must clean the lab. The best part of this cleanup is that the dissected fish become food for the numerous Northern Fulmars trailing our ship and then the lab is simply hosed down, including the computers! We clean the lab after every fishing event because if the fish scales dry out, they become impossible to remove, much like cereal crusted in a bowl! Not to mention all the fish parts would become unbearable stinky when we have a rare, sunny, warm day!

Pollock stomach contents: Amphipods (dark) and some type of fish.

Personal Log:
When I walked outside to observe the activity on the deck (where the fishing nets are located in the back of the ship) the fog was very thick. Of course, living in Dutch Harbor, I have become accustomed to such conditions but being out on the boat gave me an entirely new feeling. The boat rocked calmly, pitching every-so-often and overall there was an eerie silence among the crashing of the waves. The fog creeped aboard the boat drifting like fingers into every space available and subtly created a chill when it brushed against your neck. I can understand why sailors are prone to superstitious beliefs.

Northern Fulmars trailing the boat on the starboard side.

Later, the weather cleared into a gorgeous blue sky and the golden sun glistened on the water. I had an exciting day as I was allowed to launch an XBT and able to advance my skills in fish dissecting as I extracted stomachs and otoliths along with my regular fish duties of sorting, sexing, and measuring.
Today was a full day of work and when I when I walked into the mess hall for supper, I could not believe my eyes. There is nothing better than having a chef aboard a ship that cares for his crew. There was turkey, ham, bread dressing, mashed potatoes, cranberry sauce, candied yams, salmon tetrazzini, brown gravy, Tom Yumm Soup, dinner rolls, and corn bread! In addition, we had the lovely view of food art as our chef Ray Capati created a swan out of an apple, bouquets of baby bok choy and celery, “water lilies" made of grapefruit or oranges and mixed with flowers, and palm trees made of carrots and green bell peppers! I feel like I’m eating in a 5-star restaurant aboard the Oscar Dyson!

Ray Capati behind another fantastic, aesthetically pleasing buffet!

Animals Spotted Today:
Today is known by the “birders” from the US Fish and Wildlife folks as the Day of the Jaeger because we were able to see all three species: Longtail, Parasitic, and Pomarine!
Northern Fulmars
Black-legged Kittiwake
Common Murre
Thickbilled Murre

Slaty-backed Gull

Least Auklet
Slaty-backed Gull (Russian seagull)
Jellyfish (Chrysaora Melanaster)
Walleye Pollock
Rock Sole
Silver Salmon (Coho)
Arrowtooth Flounder
Digested shrimps, euphausiids, amphipods, and copepods from pollock stomachs!

Something to Ponder:
Random samples are important in scientific observations because we want to obtain a general idea of what is in the ocean. Imagine if a scientist only selected the largest pollock caught in the codend. How would that skew the data samples and the information given to the public about the pollock in the ocean?

Blog #3 7/23/10

NOAA Teacher at Sea: Story Miller

NOAA Ship: Oscar Dyson

Mission: Summer Pollock III

Geographical Area: Bering Sea

Date: July, 23, 2010

Time: 1240 AKST

Latitude: 60°30N

Longitude:176°29W

Wind: 8 knots (approx. 9.21 mph)

Direction: 156° (SE)

Sea Temperature: 8.9°C (approx. 48°F)

Air Temperature: 9.2°C (approx. 48.6°F)

Barometric Pressure (mb): 1008

Wave Height: 0.5 feet
Wave Swell: 5 - 6 feet

Scientific Log:

Survey Tech Robert Spina and Fisherman Mike Tortorella deploying the CTD

We started the morning by dropping a CTD (Conductivity, Temperature, Depth) and monitoring the salinity of the ocean, the temperature, and depth. Salinity, the amount of salt in the ocean, is important as the higher the salinity the more conductivity it possesses. Conductivity is necessary for many things such as scientific observation and for marine life. For example, the transducer we use to send pings of energy through the ocean relies on conductivity and sound tends to travel better through waters with a higher salinity. Sound traveling through water is also important for animal communication. Salinity can influence the presence of fish species due to the different ways they process the water (think about freshwater fish versus saltwater fish). Water temperature is important for observing climate change. Because salinity affects the density of water (My students: remember the lab where we floated the egg with salt), it can change the temperature at which the ocean freezes. A simple example is that plain distilled water freezes at 0°C but the ocean at the surface typically begins to freeze at -1.1°C. As the water depth increases, so does the salinity and therefore as the temperature decreases the ocean does not freeze. We also launched an expendable bathythermograph (XBT) which measures depth and temperature at a deeper level than the CTD. These two tests are used to characterize the Bering Sea shelf environment.

Streaming the AWT net

Pollock caught in the codend

Approximately six hours later we spotted our first school of pollock. We shot the AWT and caught a lot of two year-old pollock and a few one year-olds! The water temperature where they were located was about 2.5°C. I quickly donned my foul-weather gear and ExtraTuffs (rubber boots) and was ready to sort fish. From one sample, we sorted the fish, separating the small one year-olds from the two year-olds. Second, we cut open the fish to locate ovaries or testes. The males and the females were separated into bins and we fondly refer to the males as “Blokes” and the females as “Sheilas.” We measured their length and entered the data into the computer. With another sample, we sexed the fish, measured their length, extracted stomach samples to see what they are eating and to collect plankton samples, and last we extracted the otoliths. Otoliths are ear-bones and they are used to measure age, very much like looking at tree rings to find the age of a tree.

Me sorting the 1 year from the 2 year-olds

The walleye pollock observation has been conducted each summer since 1979 by the Midwater Assessment and Conservation Engineering (MACE) as a program of the Alaska Fisheries Science Center (AFSC) to estimate pollock abundance and distribution. The Oscar Dyson is following a route consisting of evenly spaced (20 nautical miles) parallel transects to estimate the pollock population over the entire Bering Sea shelf. So if you are tracking the ship using “Ship Tracker” this is why we are sailing in a strange pattern!

Personal Log:

 Yesterday I was slightly anxious because I chose to experiment with my sea tolerance and not take the seasickness medication. Of course the seas decided to be a little more active as we began our pollock transit. Combined waves reached 10-12 feet and I just ate plain rice and bread for supper! Today the waves are more gentle and my stomach is very excited about that! Up on the “Bridge” where the controls for driving the boat are located tends to rock with the waves the most and it was fun to try and type my blog while attempting to keep my balance! However, by the end of the day, I was well enough to help "supervise" ENS Payne in the construction of chocolate chip cookies during my time off!

Doughy thumbs up while makin' cookies!

Dissecting the fish was incredibly fun and I cannot wait to have my students try their hands at it! I was very excited to extract otoliths because those particular bones were the fossils we used to identify the different fish species at the Always Welcome Inn in Baker City, Oregon when I was conducting research in college! To see those fossils go to the following website:

http://www.eou.edu/geology/index.html

Tomorrow we will be crossing the International Dateline and theoretically will have traveled into the tomorrow of tomorrow. The Oscar Dyson has become my time machine!

Image produced by the echo sounder telling us we have pollock! Notice how it looks different from the view in the previous blog.

Animals Viewed Today:
Least Auklet
Laysan Albatross
Fork-tailed Storm Petrels
Northern Fulmars
Short-tailed Shearwaters
Walleye Pollock

Something to Ponder:
Have you ever ordered pollock? How many of you have eaten fish sticks or surimi? Most likely you have eaten pollock and thought it was cod! Where does pollock fit in the food chain in the wild?
Also, how do you know when you have crossed the International Dateline? (Hint: check the data at the beginning of my blogs.)

Blog #2 7/22/10

Black-legged Kittiwake

NOAA Teacher at Sea: Story Miller
NOAA Ship: Oscar Dyson
Mission: Summer Pollock III
Geographical Area: Bering Sea
Date: July, 22, 2010
Time: 0754 AKST
Latitude: 58°31N
Longitude:175°45W
Wind: 13-20 knots (approx. 14.96 - 23.02 mph)
Direction: 239° (SW)
Sea Temperature: 8.28°C (approx. 46.9°F)
Air Temperature: 8.03°C (approx. 46.5°F)
Barometric Pressure (mb): 1017
Wave Height: 4 feet
Sea Swells: 6 feet
Combined Wave Height: 10 - 12 feet

Scientific Log

This afternoon, we conducted a test with a drogue which is like a large sea anchor. Sea anchors allow a boat that is simply sitting in the water to not drift so far with the waves. This drogue will stabilize the camera of an experimental trawl net device, called a Cam-Trawl, and prevent it from fluttering when it is photographing the fish. The Cam-Trawl was designed by Kresimir Williams. Currently the objective of this new device is to observe the fish we see in the backscatter which are the animals we can see in the echosounder (See Figure 1).

Figure 1: Image of the echo sounder in the acoustics lab. The image on the top in the blue is representing a swarm of jellyfish. Jellyfish tend to be best seen using the 18 kHz transducer.

 In short, the ship's hull has transducers that send pings of sound energy down through the ocean and when they hit some object, such as the bottom of the ocean or a fish, some of the energy in the sound ping is returned to the ship and received by our echo sounding system in the acoustics lab of the ship.

When we locate a group of fish we want to study with the echo sounder, we have two primary methods of collecting data from the fish. The device we use the most is the AWT (Aleutian Wing Trawl) net and the other is an 83-112 bottom trawl net. The AWT is used for catching fish located at midwater depths and the other, as stated in the name, trawls the sea floor. To imagine the shape of these devices in the water, imagine a large funnel with a catch sack on the end. The beginning portion of these nets, nearest to the boat, has large meshes and its primary function is to funnel the fish toward the catch sack. As fish move farther down the net, the meshes get smaller until they reach the catch sack, which we call the codend, and once in there, the fish cannot escape. We then pull them to the surface and begin collecting data, such as size and species. The largest drawback to these methods is that the fish caught in the net will most likely die. To understand why, think of a diver in the deep ocean. If the diver comes up too fast, the body cannot adjust to the pressure fast enough as air expands, potentially causing lungs to rupture. For the fish, bringing them up too quickly causes their swim bladders to rupture. Rockfish tend to have their stomachs inverted out of their mouth. While killing the fish for research is unfortunate, it is one of the few ways we can learn about their patterns of behavior, health, and diversity.

Chris Wilson in the process of attaching buoys to stabilize the Cam-Trawl

The Cam-Trawl is an innovative experimental design that may help reduce the killing of fish and allow us to collect data from endangered or nearly extinct fish species. For example, many Rockfish species off the west coasts of California, Washington and Oregon are endangered and as a result, we do not want to catch them in our nets because we would most likely kill them. The Cam-Trawl would remedy that and would allow us to receive continuous data at each depth along its path. The other trawls catch all the fish in their path which means the collection of fish is mixed and we cannot tell the depth at which they were originally swimming or which species was at what depth. To picture how the Cam-Trawl works underwater, imagine a funnel again, except this time, there is no codend attached. At the end of the funnel, the stereocamera is positioned to photograph the fish that pass through the funnel. The resolution of the fish photos is much more advanced than what we have ever had before. This sampling technique is supposed to give us a better resolution of what we are able to “see” using acoustics (echo sounder) than the traditional midwater (AWT) and bottom trawls (83-112).

Personal Log:

Sleeping at sea was a new experience for me. The seas were only four to eight feet high which are marginal compared to the conditions this ship experiences in the winter months. Overall, I enjoyed being rocked to sleep but my 0330h alarm was not as pleasant. My room is located four flights of stairs below the bridge deck and I’ve been told it is one of the better places to be because the rocking of the boat is not as intense. The rooms are pretty cozy as space is limited but there is room for a desk, two closets and a bathroom (called a head on a ship) that reminds me of the sizes found in European hotels. I have the top bunk and each has a curtain that wraps around the entire bed so that if your roommate has a different shift than you, the light to the main room won’t be a disturbance. Of course, since I have lived in Alaska for two years, I have become accustomed to sleeping in bright conditions.

Something the non-boating community may not realize is that on a ship, it is very important that there is a night crew and a day crew operating. On the bridge where the main controls of the ship are located, there must always be a NOAA Corps Officer, with qualifications to drive the ship, on watch 24/7. However, all crews, with the exception of the kitchen, on the ship are operating around the clock. For example, there are always engineers operating in case there is some type of mechanical issue and scientists operate because there are still fish in the ocean and their behavior needs to be observed at all times.

Me trying on my "Gumby" Suit during the fire drill

The entire crew participated in a fire drill and abandon ship drill yesterday so that all hands on the ship knew where to muster for a head count and to learn how to operate the life rafts in case the ship was sinking. Additionally we needed to learn how to get into our survival suits (Gumby Suits). My first experience putting on the suit was during a field trip onto this vessel with my seventh and eighth grade students in May so I was aware of the cozy fit! Fire and abandon ship drills are practiced once a week when the ship is underway, which is very important as the crew onboard are not just NOAA employees but also in charge of fighting fires and responding to any onboard emergencies. So, if you want to be a fireman and a scientist and cannot choose, perhaps serving aboard a NOAA ship would be right up your alley!
To end my day (remember bedtime for me is early as my alarm is set for 0330) I had a “late” supper of sushi, spring rolls, meatloaf, and for dessert a fabulous set of s’mores! Who says you can’t have them on the ship?




Animals Observed:
Northern Fulmar
Crested Auklets
Tufted Puffin
Black-legged Kittiwake
Orcas

Something to Ponder:
When we are asked, “What do you want to be when you grow up?” usually we say one occupation - firefighter, actor, scientist, teacher, soldier, waitress. However, most jobs require many skills. For example, the scientists on board put a variety of skills into practice and as mentioned in the Scientific Log, scientist Kresimir Williams engineered the Cam-Trawl which employed his knowledge of the biological sciences (fish/oceanography), physical science (how to deploy the device without it breaking), and photography! So for my students, what do you want to be when you grow up?
